Product Inventory Open API

The Product Inventory Open API provides endpoints to create and retrieve product inventories.

Use this API to manage product inventory information between external systems and the ServiceNow AI Platform.

This API is included in the Product Inventory Advanced application, which is available on the ServiceNow Store.

This API is provided within the sn_prd_invt namespace.

The calling user must have the sn_prd_invt.product_inventory_integrator role.

This API creates and updates data in the following tables.

• Product Characteristics [sn_prd_invt_product_characteristics]
• Product Inventory [sn_prd_invt_product_inventory]
• Product Model [cmdb_model]
• Product Model Characteristic [sn_prd_pm_product_model_characteristic]

The Product Inventory Open API is a ServiceNow® implementation of the TM Forum Product Inventory Management API REST specification. This implementation is based on the TMF637 Product Inventory Management API REST Specification Release 19, August 2019. The Product Inventory Open API is conformance certified by TM Forum.

Product Inventory Open API - GET /sn_prd_invt/product

Retrieves a list of all product inventories.

URL format

Default URL: api/sn_prd_invt/product

Supported request parameters

Table 1. Path parameters

Name	Description
None

Table 2. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external ID matching the value of this parameter are returned in the response. Data type: String
fields	List of fields to return in the response. Invalid fields are ignored. If this parameter is not used, all fields are returned. Data type: String
limit	Maximum number of records to return. For requests that exceed this number of records, use the offset parameter to paginate record retrieval. Default: 20 Maximum: 100 Data type: Number
offset	Starting index at which to begin retrieving records. Use this value to paginate record retrieval. This functionality enables the retrieval of all records, regardless of the number of records, in small manageable chunks. Default: 0 Data type: Number
place	Filter product inventories by place. Only product offerings with a place sys_id or external id matching the value of this parameter are returned in the response. Data type: String
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String

Table 3. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 4. Request headers

Header	Description
None

Table 5. Response headers

Header	Description
Content-Range	Specifies the range of content returned in a paginated call. For example, if offset=2 and limit=3, the value of the Content-Range header is items 3-5.
Content-Type	Data format of the response body. Only supports application/json.
Link	Contains the following links to navigate through query results. first last next previous
X-Total-Count	For paginated queries, this header specifies the total number of records available on the server.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 6. Status codes

Status code	Description
200	Request successfully processed. Full resource returned in response (no pagination).
206	Partial resource returned in response (with pagination).
400	Bad request. Possible reasons: Invalid path parameter Invalid URI
404	Record not found. No records matching the query parameters are found in the table.

Response body parameters (JSON)

Name	Description
href	Relative link to the product inventory record. Data type: String
id	Sys_id of the product inventory from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
name	Name of the product inventory. Data type: String
place	Place associated with the product. Data type: String
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Initial_version or external_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.internalId	Initial_version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.internalVersion	Version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.version	External_version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productPrice	Returns an empty array. Data type: Array
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalId": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Initial_version or external_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.internalId	Initial_version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.internalVersion	Version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.version	External_version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Possible values: Customer CustomerContact Consumer Data type: String
state	Current state of the product. Data type: String

cURL request

This example retrieves all product inventories.

curl --location --request GET "https://instance.service-now.com/api/sn_prd_invt/product" \
--user 'username':'password'

Response body.

[
   {
      "id": "037fd87ec3603010abc8b5183c40ddf2",
      "relatedParty": [
         {
            "id": "ffc68911c35420105252716b7d40dd55",
            "name": "Example Company",
            "@type": "RelatedParty",
            "@referredType": "Customer"
         },
         {
            "id": "eaf68911c35420105252716b7d40ddde",
            "name": "Sally Thomas",
            "@type": "RelatedParty",
            "@referredType": "CustomerContact"
         }
      ],
      "name": "Routing and Configuration PI0000318",
      "productSpecification": {
         "id": "aec57e981bb420106ba59acf034bcb08",
         "name": "Routing and Configuration",
         "version": "",
         "internalVersion": "1",
         "internalId": "aec57e981bb420106ba59acf034bcb08"
      },
      "status": "Active",
      "productOffering": {
         "id": "69017a0f536520103b6bddeeff7b127d",
         "name": "Premium SD-WAN Offering",
         "version": "",
         "internalVersion": "1",
         "internalId": "69017a0f536520103b6bddeeff7b127d"
      },
      "product": "ce0b52c7532520103b6bddeeff7b12f5",
      "place": {
         "id": "25ab9c4d0a0a0bb300f7dabdc0ca7c1c",
         "name": "100 South Charles Street, Baltimore,MD"
      },
      "productCharacteristic": [],
      "productRelationship": [],
      "realizingService": [],
      "realizingResource": [
         {
            "id": "9b2fa60b536520103b6bddeeff7b1233",
            "name": "Route Target"
         }
      ],
      "productPrice": [],
      "href": "/api/sn_prd_invt/product/037fd87ec3603010abc8b5183c40ddf2",
      "billingAccount": "Not Specified."
   }
]

Product Inventory Open API - GET /sn_prd_invt/product/{id}

Retrieves a specified product inventory record.

URL format

Default URL: /api/sn_prd_invt/product/{id}

Supported request parameters

Table 7. Path parameters

Name	Description
id	Sys_id of the product inventory to retrieve. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String

Table 8. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external id matching the value of this parameter are returned in the response. Data type: String
fields	List of fields to return in the response. Invalid fields are ignored. If this parameter is not used, all fields are returned. Data type: String
place	Filter product inventories by place. Only product offerings with a place sys_id or external id matching the value of this parameter are returned in the response. Data type: String
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String

Table 9. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 10. Request headers

Header	Description
None

Table 11. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 12. Status codes

Status code	Description
200	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Invalid path parameter Invalid URI
404	Record not found. Record associated with the ID is not found in the table.

Response body parameters (JSON)

Name	Description
href	Relative link to the product inventory record. Data type: String
id	Sys_id of the product inventory from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
name	Name of the product inventory. Data type: String
place	Place associated with the product. Data type: String
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Initial_version or external_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.internalId	Initial_version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.internalVersion	Version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.version	External_version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productPrice	Returns an empty array. Data type: Array
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalId": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Initial_version or external_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.internalId	Initial_version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.internalVersion	Version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.version	External_version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Data type: String
state	Current state of the product. Data type: String

cURL request

This example retrieves a specified product inventory.

curl -X GET 'https://instance.service-now.com/api/sn_prd_invt/product/037fd87ec3603010abc8b5183c40ddf2' \
--user 'username':'password'

Output:

{
   "id": "037fd87ec3603010abc8b5183c40ddf2",
   "relatedParty": [
      {
         "id": "ffc68911c35420105252716b7d40dd55",
         "name": "Example Company",
         "@type": "RelatedParty",
         "@referredType": "Customer"
      },
      {
         "id": "eaf68911c35420105252716b7d40ddde",
         "name": "Sally Thomas",
         "@type": "RelatedParty",
         "@referredType": "CustomerContact"
      }
   ],
   "name": "Routing and Configuration PI0000318",
   "productSpecification": {
      "id": "aec57e981bb420106ba59acf034bcb08",
      "name": "Routing and Configuration",
      "version": "",
      "internalVersion": "1",
      "internalId": "aec57e981bb420106ba59acf034bcb08"
   },
   "status": "Active",
   "productOffering": {
      "id": "69017a0f536520103b6bddeeff7b127d",
      "name": "Premium SD-WAN Offering",
      "version": "",
      "internalVersion": "1",
      "internalId": "69017a0f536520103b6bddeeff7b127d"
   },
   "product": "ce0b52c7532520103b6bddeeff7b12f5",
   "place": {
      "id": "25ab9c4d0a0a0bb300f7dabdc0ca7c1c",
      "name": "100 South Charles Street, Baltimore,MD"
   },
   "productCharacteristic": [],
   "productRelationship": [],
   "realizingService": [],
   "realizingResource": [
      {
         "id": "9b2fa60b536520103b6bddeeff7b1233",
         "name": "Route Target"
      }
   ],
   "productPrice": [],
   "href": "/api/sn_prd_invt/product/037fd87ec3603010abc8b5183c40ddf2",
   "billingAccount": "Not Specified."
}

Product Inventory Open API - GET /sn_prd_invt/productinventory

Retrieves a list of all product inventories.

Important:

Starting with the Tokyo release, this endpoint is deprecated. The new version of this endpoint is Product Inventory Open API - GET /sn_prd_invt/product.

URL format

Default URL: api/sn_prd_invt/productinventory

Supported request parameters

Table 13. Path parameters

Name	Description
None

Table 14. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external id matching the value of this parameter are returned in the response. Data type: String
fields	List of fields to return in the response. Invalid fields are ignored. If this parameter is not used, all fields are returned. Data type: String
limit	Maximum number of records to return. For requests that exceed this number of records, use the offset parameter to paginate record retrieval. Default: 20 Maximum: 100 Data type: Number
offset	Starting index at which to begin retrieving records. Use this value to paginate record retrieval. This functionality enables the retrieval of all records, regardless of the number of records, in small manageable chunks. Default: 0 Data type: Number
place	Filter product inventories by place. Only product offerings with a place sys_id or external id matching the value of this parameter are returned in the response. Data type: String
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String

Table 15. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 16. Request headers

Header	Description
None

Table 17. Response headers

Header	Description
Content-Range	Specifies the range of content returned in a paginated call. For example, if offset=2 and limit=3, the value of the Content-Range header is items 3-5.
Content-Type	Data format of the response body. Only supports application/json.
Link	Contains the following links to navigate through query results. first last next previous
X-Total-Count	For paginated queries, this header specifies the total number of records available on the server.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 18. Status codes

Status code	Description
200	Request successfully processed. Full resource returned in response (no pagination).
206	Partial resource returned in response (with pagination).
400	Bad request. Possible reasons: Invalid path parameter Invalid URI
404	Record not found. No records matching the query parameters are found in the table.

Response body parameters (JSON)

Name	Description
id	Sys_id of the product inventory from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
name	Name of the product inventory. Data type: String
place	Place associated with the product. Data type: String
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Sys_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Sys_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. Data type: String
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact] or Consumer [csm_consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Possible values: customer customerContact consumer Data type: String
state	Current state of the product. Data type: String

cURL request

This example retrieves all product inventories.

curl "https://instance.servicenow.com/api/sn_prd_invt/productinventory" \
--request GET \
--user 'username':'password'

Response body.

[
   {
      "id": "075072aec3a83010abc8b5183c40dd44",
      "relatedParty": [
         {
            "id": "ffc68911c35420105252716b7d40dd55",
            "name": "Funco Intl",
            "@type": "RelatedParty",
            "@referredType": "Customer"
         },
         {
            "id": "eaf68911c35420105252716b7d40ddde",
            "name": "Sally Thomas",
            "@type": "RelatedParty",
            "@referredType": "CustomerContact"
         }
      ],
      "name": "Firewall Administration PI0000300",
      "productSpecification": {
         "id": "31c5caff07266010a7955b7e0ad3006b",
         "name": "Firewall Administration"
      },
      "status": "Active",
      "productOffering": {
         "id": "",
         "name": ""
      },
      "place": {
         "id": "920cf6ac73d423002728660c4cf6a799",
         "name": "200 South James street,Atlanta, GA"
      },
      "productCharacteristic": [
         {
            "name": "Firewall Administration CPE Type",
            "valueType": "Choice",
            "value": "Physical"
         },
         {
            "name": "Configuration and Policy backup",
            "valueType": "Choice",
            "value": ""
         },
         {
            "name": "Firewall Administration CPE ID",
            "valueType": "Single Line Text",
            "value": "CPE123456789"
         },
         {
            "name": "Remote CLI troubleshoot support",
            "valueType": "Choice",
            "value": ""
         },
         {
            "name": "Firewall Administration CPE Model",
            "valueType": "Choice",
            "value": "9300 series"
         }
      ],
      "productRelationship": [],
      "realizingService": [],
      "realizingResource": [
         {
            "id": "3546463307666010a7955b7e0ad3005d",
            "name": "Cisco Firewall Management system"
         }
      ]
   },
   {
      "id": "0303a8ea74418510f877ca57242ff96d",
      "relatedParty": [
         {
            "id": "ffc68911c35420105252716b7d40dd55",
            "name": "Funco Intl",
            "@type": "RelatedParty",
            "@referredType": "Customer"
         },
         {
            "id": "eaf68911c35420105252716b7d40ddde",
            "name": "Sally Thomas",
            "@type": "RelatedParty",
            "@referredType": "CustomerContact"
         }
      ],
      "name": "SD-WAN Edge Device PI0001114",
      "productSpecification": {
         "id": "39b627aa53702010cd6dddeeff7b1202",
         "name": "SD-WAN Edge Device"
      },
      "status": "Installation Pending",
      "productOffering": {
         "id": "69017a0f536520103b6bddeeff7b127d",
         "name": "Premium SD-WAN Offering"
      },
      "place": "",
      "productCharacteristic": [],
      "productRelationship": [],
      "realizingService": [
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         },
         {
            "id": "16d79ec3532520103b6bddeeff7b12a6",
            "name": "SD WAN Optimization Service"
         },
         {
            "id": "16d79ec3532520103b6bddeeff7b12a6",
            "name": "SD WAN Optimization Service"
         },
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         },
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         },
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         }
      ],
      "realizingResource": [
         {
            "id": "493fa60b536520103b6bddeeff7b12b6",
            "name": "Customer Premise SD-WAN Router"
         }
      ]
   }
]

Product Inventory Open API - GET /sn_prd_invt/productinventory/{inventoryId}

Retrieves a product inventory.

Important:

Starting with the Tokyo release, this endpoint is deprecated. The new version of this endpoint is Product Inventory Open API - GET /sn_prd_invt/product/{id}.

URL format

Default URL: /api/sn_prd_invt/productinventory/{inventoryId}

Supported request parameters

Table 19. Path parameters

Name	Description
inventoryId	Sys_id of the product inventory to retrieve. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String

Table 20. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external id matching the value of this parameter are returned in the response. Data type: String
fields	List of fields to return in the response. Invalid fields are ignored. If this parameter is not used, all fields are returned. Data type: String
place	Filter product inventories by place. Only product offerings with a place sys_id or external id matching the value of this parameter are returned in the response. Data type: String
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String

Table 21. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 22. Request headers

Header	Description
None

Table 23. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 24. Status codes

Status code	Description
200	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Invalid path parameter Invalid URI
404	Record not found. Record associated with the ID is not found in the table.

Response body parameters (JSON)

Name	Description
id	Sys_id of the product inventory from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
name	Name of the product inventory. Data type: String
place	Place associated with the product. Data type: String
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Sys_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Sys_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. Data type: String
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Possible values: Customer CustomerContact Consumer Data type: String
state	Current state of the product. Data type: String

cURL request

This example retrieves a product inventory for an SD-WAN service package.

curl --location --request GET 'https:// instance.servicenow.com/api/sn_prd_invt/productinventory/074450fc74918d10f877ca57242ff9e3' \
--user 'username':'password'

Output:

{
   "id": "074450fc74918d10f877ca57242ff9e3",
   "relatedParty": [
      {
         "id": "ffc68911c35420105252716b7d40dd55",
         "name": "Funco Intl",
         "@type": "RelatedParty",
         "@referredType": "Customer"
      },
      {
         "id": "eaf68911c35420105252716b7d40ddde",
         "name": "Sally Thomas",
         "@type": "RelatedParty",
         "@referredType": "CustomerContact"
      }
   ],
   "name": "SD-WAN Service Package PI0001576",
   "productSpecification": {
      "id": "cfe5ef6a53702010cd6dddeeff7b12f6",
      "name": "SD-WAN Service Package"
   },
   "status": "Installation Pending",
   "productOffering": {
      "id": "69017a0f536520103b6bddeeff7b127d",
      "name": "Premium SD-WAN Offering"
   },
   "place": "",
   "productCharacteristic": [],
   "productRelationship": [
      {
         "id": "a74490fc74918d10f877ca57242ff942",
         "name": "SD-WAN Edge Device PI0001582",
         "relationshipType": "Bundles"
      },
      {
         "id": "b85414fc74918d10f877ca57242ff90e",
         "name": "SD-WAN Controller PI0001602",
         "relationshipType": "Bundles"
      },
      {
         "id": "d74490fc74918d10f877ca57242ff907",
         "name": "SD-WAN Security PI0001577",
         "relationshipType": "Bundles"
      }
   ],
   "realizingService": [],
   "realizingResource": []
}

Product Inventory Open API - POST /sn_prd_invt/product

Creates a product inventory record.

URL format

Default URL: /api/sn_prd_invt/product

Supported request parameters

Table 25. Path parameters

Name	Description
None

Table 26. Query parameters

Name	Description
None

Table 27. Request body parameters (JSON)

Name	Description
name	Required. Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String Default: Blank string
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String Default: Blank string
productCharacteristic.value	Value of the characteristic. Data type: String Default: Blank string
productOffering	Required. Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Required. Initial_version or external_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.internalVersion	Version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String Default: Blank string
productOffering.version	External_version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Required if using the productRelationship parameter. Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. The only valid value is child. Data type: String Default: Blank string
productSpecification	Required. Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Required. Initial_version or external_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.internalVersion	Version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.version	External_version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Required if using the realizingResource parameter. Sys_id of the realizing resource. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Required if using the realizingService parameter. Sys_id of the realizing service. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Required if using the relatedParty parameter. Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Possible values: customer customer_contact consumer Data type: String Default: Blank string
state	Current state of the product. Possible values: active change_pending inactivation_pending inactive installation_pending Data type: String Default: installation_pending

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 28. Request headers

Header	Description
Accept	Data format of the response body. Only supports application/json.
Content-Type	Data format of the request body. Only supports application/json.

Table 29. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 30. Status codes

Status code	Description
201	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Empty payload. Invalid payload. Mandatory field missing: <field name>

Response body parameters (JSON)

Name	Description
href	Relative link to the product inventory record. Data type: String
id	Sys_id of the product inventory from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
name	Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Initial_version or external_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.internalId	Initial_version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.internalVersion	Version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.version	External_version of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productPrice	Returns an empty array. Data type: Array
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalId": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Initial_version or external_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.internalId	Initial_version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.internalVersion	Version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
productSpecification.version	External_version of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Located in the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Possible values: Customer CustomerContact Consumer Data type: String
state	Current state of the product. Data type: String

cURL request

This example creates a product inventory for a voice over IP solution for a user.

curl -X POST "https://instance.service-now.com/api/sn_prd_invt/product" \
--header "Accept: application/json" \
--header "Content-Type: application/json" \
--user "username":"password" \
--data "[
   {
      "pid": "PO-456",
      "description": "inventory description",
      "isBundle": false,
      "name": "Voice Over IP Basic instance for Jean",
      "productOffering": {
         "@referredType": "ProductOffering",
         "name": "Premium SD-WAN Offering",
         "id": "69017a0f536520103b6bddeeff7b127d"
      },
      "productCharacteristic": [],
      "productRelationship": [
         {
            "productId": "fa6d13f45b5620102dff5e92dc81c77f",
            "relationshipType": "child"
         }
      ],
      "realizingService": {
         "id": "fe6d13f45b5620102dff5e92dc81c786",
         "relationshipType": "child"
      },
      "realizingResource": {
         "id": "326d13f45b5620102dff5e92dc81c78c",
         "relationshipType": "child"
      },
      "relatedParty": [
         {
            "@referredType": "CustomerContact",
            "@type": "RelatedParty",
            "name": "Sally Thomas",
            "id": "eaf68911c35420105252716b7d40ddde"
         },
         {
            "@referredType": "Customer",
            "@type": "RelatedParty",
            "name": "Funco Intl",
            "id": "ffc68911c35420105252716b7d40dd55"
         }
      ],
      "productSpecification": {
         "@referredType": "ProductSpecification",
         "@type": null,
         "name": null,
         "id": "3ee1fdb1c3331010d216b5183c40dd81",
         "internalVersion": "1"
      },
      "bundle": false
   }
]"

Response body.

{
   "pid": "PO-456",
   "description": "inventory description",
   "isBundle": false,
   "name": "Voice Over IP Basic instance for Jean",
   "productOffering": {
      "@referredType": "ProductOffering",
      "name": "Premium SD-WAN Offering",
      "id": "69017a0f536520103b6bddeeff7b127d",
      "internalVersion": "1",
      "version": null,
      "status": "published",
      "internalId": "69017a0f536520103b6bddeeff7b127d"
   },
   "productCharacteristic": [],
   "productRelationship": [
      {
         "productId": "fa6d13f45b5620102dff5e92dc81c77f",
         "relationshipType": "child"
      }
   ],
   "realizingService": {
      "id": "fe6d13f45b5620102dff5e92dc81c786",
      "relationshipType": "child"
   },
   "realizingResource": {
      "id": "326d13f45b5620102dff5e92dc81c78c",
      "relationshipType": "child"
   },
   "relatedParty": [
      {
         "@referredType": "CustomerContact",
         "@type": "RelatedParty",
         "name": "Sally Thomas",
         "id": "eaf68911c35420105252716b7d40ddde"
      },
      {
         "@referredType": "Customer",
         "@type": "RelatedParty",
         "name": "Example Company",
         "id": "ffc68911c35420105252716b7d40dd55"
      }
   ],
   "productSpecification": {
      "@referredType": "ProductSpecification",
      "@type": null,
      "name": null,
      "id": "3ee1fdb1c3331010d216b5183c40dd81",
      "internalVersion": "1",
      "version": null,
      "status": "published",
      "internalId": "3ee1fdb1c3331010d216b5183c40dd81"
   },
   "bundle": false,
   "productPrice": [],
   "id": "25b07475471789108761b955d36d439d",
   "href": "/api/sn_prd_invt/product/25b07475471789108761b955d36d439d"
}

Product Inventory Open API - POST /sn_prd_invt/productinventory

Creates a product inventory.

Important:

Starting with the Tokyo release, this endpoint is deprecated. The new version of this endpoint is Product Inventory Open API - POST /sn_prd_invt/product.

URL format

Default URL: /api/sn_prd_invt/productinventory

Supported request parameters

Table 31. Path parameters

Name	Description
None

Table 32. Query parameters

Name	Description
None

Table 33. Request body parameters (JSON)

Name	Description
name	Required. Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String Default: Blank string
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String Default: Blank string
productCharacteristic.value	Value of the characteristic. Data type: String Default: Blank string
productOffering	Required. Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Required. Sys_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String Default: Blank string
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Required if using the productRelationship parameter. Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. The only valid value is child. Data type: String Default: Blank string
productSpecification	Required. Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Required. Sys_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Required if using the realizingResource parameter. Sys_id of the realizing resource from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. The only valid value is child. Data type: String Default: Blank string
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Required if using the realizingService parameter. Sys_id of the realizing service from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. The only valid value is child. Data type: String Default: Blank string
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Required if using the relatedParty parameter. Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact], or Consumer [csm_Consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Possible values: customer customer_contact consumer Data type: String Default: Blank string
state	Current state of the product. Possible values: active change_pending inactivation_pending inactive installation_pending Data type: String Default: installation_pending

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 34. Request headers

Header	Description
Accept	Data format of the response body. Only supports application/json.
Content-Type	Data format of the request body. Only supports application/json.

Table 35. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 36. Status codes

Status code	Description
201	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Empty payload. Invalid payload. Mandatory field missing: <field name>

Response body parameters (JSON)

Name	Description
id	Sys_id of the product inventory from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
name	Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String
productCharacteristic	List of product characteristics. Data type: Array "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Sys_id of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productOffering.name	Name of the product offering. Located in the Product Offering [sn_prd_pm_product_offering] table. Data type: String
productRelationship	List of related products. Data type: Array "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Sys_id of the product specification. Located in the Product Specification [sn_prd_pm_product_specification] table. Data type: String
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingResource.type	Type of the realizing resource. Data type: String
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service from the Product Inventory [sn_prd_invt_product_inventory] table. Data type: String
realizingService.type	Type of the realizing service. Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Located in the Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer] table. Data type: String
relatedParty.@referredType	Type of customer. Possible values: Customer CustomerContact Consumer Data type: String
state	Current state of the product. Data type: String

cURL request

This example creates a product inventory for a voice over IP solution for a user.

curl --location --request POST “https://instance.servicenow.com/api/sn_prd_invt/productinventory” \
--header “Content-Type: application/json” \
--data-raw '[
    {
        "pid": "demoInventory",
        "description": "inventory description",
        "isBundle": false,
        "name": "Voice Over IP Basic instance for Jean",
        "productOffering": {
            "id": "69017a0f536520103b6bddeeff7b127d",
            "name": "Premium SD-WAN Offering",
            "@referredType": "ProductOffering"
        },
        "productCharacteristic": [
            {
                "name": "CPE Type",
                "valueType": "choice",
                "value": "Virtual"
            },
            {
                "name":"Routing",
                "valueType": "choice",
                "value": "Premium"
            }
        ],
        "productRelationship": [
            {
                "productId": "7e6d13f45b5620102dff5e92dc81c787",
                "relationshipType": "child"
            }
        ],
        "relatedParty": [
            {
                "id": "eaf68911c35420105252716b7d40ddde",
                "name": "Sally Thomas",
                "role": "User",
                "@type": "RelatedParty",
                "@referredType": "CustomerContact"
            },
            {
                "id": "ffc68911c35420105252716b7d40dd55",
                "name": "Funco Intl",
                "@type": "RelatedParty",
                "@referredType": "Customer"
            }
        ],
        "productSpecification": {
            "id": "cfe5ef6a53702010cd6dddeeff7b12f6",
            "@referredType": "ProductSpecification",
            "version": "1"
        }
    }
]'
--user 'username':'password'

Response body.

{
   "pid": "demoInventory",
   "description": "inventory description",
   "isBundle": false,
   "name": "Voice Over IP Basic instance for Jean",
   "productOffering": {
      "id": "69017a0f536520103b6bddeeff7b127d",
      "name": "Premium SD-WAN Offering",
      "@referredType": "ProductOffering"
   },
   "productCharacteristic": [
      {
         "name": "CPE Type",
         "valueType": "choice",
         "value": "Virtual"
      },
      {
         "name": "Routing",
         "valueType": "choice",
         "value": "Premium"
      }
   ],
   "productRelationship": [
      {
         "productId": "7e6d13f45b5620102dff5e92dc81c787",
         "relationshipType": "child"
      }
   ],
   "relatedParty": [
      {
         "id": "eaf68911c35420105252716b7d40ddde",
         "name": "Sally Thomas",
         "role": "User",
         "@type": "RelatedParty",
         "@referredType": "CustomerContact"
      },
      {
         "id": "ffc68911c35420105252716b7d40dd55",
         "name": "Funco Intl",
         "@type": "RelatedParty",
         "@referredType": "Customer"
      }
   ],
   "productSpecification": {
      "id": "cfe5ef6a53702010cd6dddeeff7b12f6",
      "@referredType": "ProductSpecification",
      "version": "1"
   },
   "id": "3ac715c6745d8150f877ca57242ff97a"
}
