how to trigger a flow from flow designer using ui action script

[Alon Grod]

Hi,

How can trigger a flow (from flow designer) ui UI Action Script ?

[Dr Atul G- LNG]

https://www.servicenow.com/community/developer-forum/how-to-trigger-a-flow-from-a-ui-action/m-p/2162...

https://servicenow-events-or-lab-guidebo.gitbook.io/knowledge-2026/knowledge-2026/ccl7230-k26/exerci...

https://www.servicenow.com/community/service-management-forum/i-want-to-execute-the-flow-of-the-flow...

var flowInputs = {};
flowInputs['current'] = current;
flowInputs['table_name'] = current.getTableName();

var result = sn_fd.Flow.startAsync('flow name', flowInputs);

[Tanushree Maiti]

Hi @Alon Grod

Refer: https://developer.servicenow.com/dev.do#!/learn/learning-plans/australia/servicenow_application_deve...

https://developer.servicenow.com/dev.do#!/reference/api/zurich/server/ScriptableFlowAPI

https://www.servicenow.com/community/servicenow-ai-platform-forum/flow-triggered-from-another-flows-...

  var inputs = {};
        inputs['table_name'] = '<your_Table_Name>';
        inputs['current'] = current; // GlideRecord of table: incident
       sn_fd.FlowAPI.startFlow('global.[internal name of flow]', inputs);
        // Execute Synchronously: Run in foreground.
        sn_fd.FlowAPI.executeFlow('global.[internal name of flow]', inputs);
