Create new process start/end condition

Crop your process by setting the new process start condition and new process end condition. This configuration defines which part of the process should be included in the Process Mining project and made available for analysis. The Create new process start and end condition forms have the same fields.

Tableau 1. Create new process start condition form

Field	Description
Name	Name of the condition.
Table	Table for the condition. This field is automatically populated with the table selected in your table configuration record.
Condition type	The condition type used for this condition. Field/Value condition Contextual field/Value condition Performed by And Or Process start condition Process stop condition
Language	Language for the condition. This field is automatically populated with the current language.
Field	Field used for the condition. These are field from the table in the Table field. The designated start and stop field should be configured as activity definition to make the start or stop condition working.
Predicate	The qualifier for the condition. is is not is anything is one of is not one of starts with ends with contains does not contain Remarque : When you select "is one of", you can select multiple values at once. Type the first two letters, and select the Select all icon to select all matching values.
Field value	The value use along with the predicate to define this condition. If the field is a reference field, you can select values using the reference icon ().
Occurrence(s) to match	Select the occurrence to match for this condition. All First only Last only
Contextual Condition	Additional condition that must be true when the current condition is triggered. For example, you configure your condition to trigger when a record is in the New state. If you wanted to also specify that the Priority is high, you can do that using the Contextual Condition field.
