Publish or unpublish a snapshot

Publish a snapshot so that it can be exported to enable the CI/CD pipeline to access and use the config data. Exporters can execute only on published snapshots.

시작하기 전에

중요사항:

DevOps Config is now deprecated and no longer supported or available for new activation.

Role required: CDM Editor [sn_cdm.cdm_editor] or CDM Admin [sn_cdm.cdm_admin]

이 태스크 정보

• You publish a snapshot when you feel that the deployable that it represents is ready to export to the pipeline.
• While defining or updating a deployable, you can specify that only validated snapshots can be published.
• A deployable must be connected to a service to publish its snapshots.
• If a published deployable is disconnected from services, then you can perform the following actions, but cannot publish snapshots of the deployable until it is connected to a service:
  • Edit config data.
  • Create snapshots.
  • Validate snapshots.
  • Fix validation errors.

팁:

You can add a text description of a snapshot or rename it on the Details tab for the snapshot.

• When exporters look for the latest snapshot, they should look for the latest created snapshot that is published.
• The published_date is the data at which the publish happens.
• The unpublish snapshot action removes the publish flag and removes the published_date value.

프로시저

1. Use either of the following methods to publish a snapshot:
   • On any tab for an open snapshot, select Publish.
   • On the Version tab for an application, select Publish from the Actions menu for the snapshot.



2. View info

   표 1. Information on the snapshot header and Details tab

   Changeset number	The system auto-assigns the changeset number. The system uses the number as the default changeset name.
   Changeset name / Description	The system uses the changeset number as the default changeset name. Update the fields to help other users by changing to a more user-friendly name or by associating descriptive information with the changeset.
   Deployable	Deployable on which the snapshot is based.
   Validation status	Not validated: No policy has been executed against the snapshot. Passed: The snapshot has passed all policy executions. Failed: The snapshot has failed one or more policy executions. In progress: Policies are currently executing. Execution error: A policy failed to execute to completion.
   Created / Created by	User that created the changeset and timestamp` of creation.
   Published on	Timestamp when the snapshot was published.

3. Use either of the following methods to unpublish a snapshot:
   • On any tab for an open snapshot, select Unpublish.
   • On the Version tab for an application, select Unpublish from the Actions menu for the snapshot.
