Premium chat

ServiceNow® Otto for Virtual Agent premium chat is a contextual chat experience that appears throughout the platform, adapting its behavior and interface based on where users are and what they're doing.

To access the ServiceNow Otto for Virtual Agent premium chat screen, select the ServiceNow Otto icon or enter text in the omnibar.

After the premium chat screen appears, begin entering a prompt in the chat input box. You can enter the entire prompt or select one of the recommended prompts that displays below the chat input box. Recommended prompts may include:

• Related workflows and actions
• Keyword-based prompts
• Direct links to relevant content

Note:

For more information about how ServiceNow Otto for Virtual Agent and ServiceNow Otto for AI Search combine to include recommended prompts, see Auto-complete suggestion types included with ServiceNow Otto for AI Search.

Chat input box features

The chat input box has these features:

Multi-line input

The chat input box starts as a single-line field and automatically expands to multi-line mode when text exceeds the available width.

Plus sign icon

Select the plus sign (+) icon to access additional options including web search and file upload.

Web search

When you select the plus sign icon, the Web search toggle appears. You can toggle the Web search option on to receive responses that combine both internal knowledge base results and web search results. You can toggle the web search on or off at any time during a conversation.

File upload

You can upload files by selecting the file upload icon or by dragging and dropping files directly into the chat input box. You can upload a maximum of 5 files per conversation and a total upload limit of 30 MB. Supported file formats are:

• PDF
• JPEG
• TXT
• CSV
• PNG

Navigating the chat window resizing options and controls toolbar

The ServiceNow Otto sub-header consists of four elements. The following figure and table shows an example and description of those elements.

Figure 1. Example of chat controls

Table 1. ServiceNow Otto sub-header elements

Element	Description
1. Chats ()	All chats appear. Chats are organized with the most recent conversations at the top. Selecting a chat opens the chat in the conversation area. If there are unread chats or notifications, a badge number appears on the Chats icon (). Any unread chat or notification appears with a red dot next to it and the chat title appears in bold. Additionally, if you switch to a new chat while another active chat is ongoing, a pop-up message on the Chats icon () appears: Your previous chat was saved. You can revisit all of your past chats and continue ones that are still active. The following list includes the chat sections that you may see in the chats area. Active: Chats where you can continue the conversation. If applicable, active chats move to the Closed chats section after two hours of inactivity. This 2 hour time limit can be configured within the Messaging Channels {sys_cs_channel.list} table. To change the inactivity time limit, from the Messaging Channels {sys_cs_channel.list} table, select the NASS record and populate the Conversation Idle Timeout field with your preferred active chat time limit. If you have no active chats, No chatter at the moment is displayed. If more than 12 active chats are running, a Show more link appears to view more chats. Selecting Show more displays an additional 10 chats. Updates: Updates for important notifications and reminders can be configured to display. When sn_nowassist_va.nass_notification_enabled is set to true (the default), simple (nonactionable) Virtual Agent notifications appear on your portal home page. After selecting a notification, you’re redirected to this Updates section. If you have no updates, You're all caught up is displayed. If more than four updates are available, a Show more link appears to view more updates. Selecting Show more displays an additional 10 updates. Note: If sn_nowassist_va.nass_notification_enabled is set to false, the Updates section doesn't appear. Closed: Closed chats can be configured to display. You know that a message has closed when the designated time has passed (2 hours of inactivity) or you receive the following response in the chat: It looks like you're finished with this chat, so I'll go ahead and close it. Turn on closed chats by selecting the Show closed chats check box within Conversational Interfaces > Assistants > [Selected Assistant Name] > Chat experience > Closed chats. After being turned on, closed chats are displayed for as long as they’re available within the Conversations (sys_cs_conversation) table. Closed chats appear in a read-only mode and can’t become active again. If more than four closed chats are available, a Show more link appears to view more closed chats. Selecting Show more displays an additional 10 closed chats. After a conversation has closed, you can’t reopen it. Hovering over a closed chat displays the delete icon (). Confirm the chat deletion on the Delete this chat? modal to permanently delete the chat from the interface.
2. [Chat name]	The name of the conversation. If you select a promoted asset or query, that asset's title appears as the chat name. If instead you enter an utterance into the Reply to field, your initial utterance becomes the chat name. The chat name appears in both the ServiceNow Otto subheader and Chats list > Active section.
3. New chat ()	A new conversation begins. You may be prompted with a greeting message along with any promoted conversational assets such as topics, subflows, and/or actions, or suggested queries.
4. Support and settings ()	Support contact information such as phone numbers and email addresses are listed. If live agents are available, an active Contact Live Agent button is displayed. Although multiple active conversations are possible, you can only have one live agent conversation at a time. Selecting Contact Live Agent begins a chat with a live agent. After a live agent enters the chat, the Contact Live Agent button becomes inactive. If live agents are unavailable, an inactive No live agents currently available button is displayed. Settings toggles for Audio notifications and Notifications appear. By default, audio notifications are turned on and notifications are turned off. If admins have enabled notifications within the guided setup, users can turn on the notifications.
5. Interactive view ( or )	Note: This icon only appears in the sub-header whenever the interactive view is available. Open or close the interactive view. The interactive view appears to the right of the conversational chat area. The drop-down selector displays the names of all interactive views opened in the current conversation, including Knowledge Base articles, catalog forms, org charts, and AI agent widgets.Interactive view is only available in the following scenarios: An organizational chart is available to view. A document was uploaded and you choose to preview the document. A source is available and you choose to select and view the source content.

Chatting with Virtual Agent

After the user enters an utterance and a search result is found, a synthesized response may appear. A synthesized response includes a brief summary of the requested information and search results along with Genius Results. For more information on how these search results are found, see Actions Genius Results and Knowledge base articles Genius Results.

If multiple results are found, you can follow inline citations to either begin an action or learn more. The option to Show sources appears at the end of the synthesized response for internal and external Knowledge Base articles. Virtual Agent can only return available catalog items that match a user's request when the ServiceNow Otto Multi-Turn Catalog Ordering skill is enabled.

Note:

For full catalog functionality, enable the generative AI experience for catalog item request submissions. For more information, see Configure ServiceNow Otto in Conversational Catalog Request.

Whenever only a single search result for topics is found, the synthesized response and options are bypassed by default and users are brought directly into that action's flow. You may consider bypassing the synthesized response and options by automatically launching catalog items, too. For more information on automatically launching single search result actions, search for the sn_nowassist_va.synthesized_autostart_items system property in Available system properties.

You can create a new query from within a ServiceNow Otto conversation using mid-topic discovery. For more information, see Mid-topic switching during ServiceNow Otto for Virtual Agent conversations.

If AI Guardian is enabled and your request contains profane content, the Virtual Agent responds with a message prompting you to re-enter an appropriate request without profanity or offensive content. If your request is too ambiguous on the portal search, a synthesized response appears along with an Ask a follow up option. Selecting the Ask a follow up option redirects you to a Virtual Agent chat. In the Virtual Agent chat, you can submit your follow-up question or request, but the synthesized response links are only available to select on the portal page and are unavailable to select in the chat window. If your follow-up question or request is too ambiguous in the Virtual Agent chat, Virtual Agent asks a clarifying question and displays the go to search results icon () in the feedback panel.

Each Virtual Agent response includes a feedback icons panel. The feedback icons panel appears on the latest Virtual Agent response and whenever you hover over any Virtual Agent response. You can indicate if the response was helpful by selecting the like thumbs up icon (). If the response wasn't helpful, select the dislike thumbs down icon (). When you select the thumbs up or thumbs down icon, you are prompted to provide detailed feedback by selecting one or more reason check boxes. You can also select Other to add comments or suggestions (up to 300 characters). After making your selection, select Submit to submit your feedback or select X to close the dialog without submitting feedback. All submitted feedback is captured, stored, and made available through analytic dashboards.

Figure 2. Example of additional feedback panel from thumbs down icon

Depending on the context of the response, an additional go to search results icon () may appear in the feedback icons panel. This icon appears alongside synthesized responses in Virtual Agent, clarifying questions in Virtual Agent, and regular search results or Virtual Agent fallback topics whenever a synthesized response is unavailable. Selecting the go to search results icon () redirects you to the search results page and begins a search query using the last five chat utterances you entered. Additionally, a copy message icon () appears on received Virtual Agent responses.

Figure 3. Example of feedback panel in premium chat

Responses generated in ServiceNow Otto for Virtual Agent can come from a combination of catalog items, Virtual Agent topics, subflows and actions, knowledge articles, attachments, external content sources, and people citations. Inline citations appear at the end of the relevant synthesized response sentence. Selecting an inline citation results in a popover containing either a link to an article or source, or a description and action to start the action. The following options may appear as synthesized response in-line citations depending on what search results are returned:

• Catalog
• Topic, subflows, or actions
• Q&A Knowledge Base articles
• External content connections
• People
• Extended entities and additional records

Note:

Q&A Knowledge Base and external content connection citations also appear within the expandable Show sources option.

Response feedback

Each Virtual Agent response includes a feedback icons panel. The feedback icons panel appears on the latest Virtual Agent response and whenever you hover over any Virtual Agent response. You can indicate if the response was helpful by selecting the like thumbs up icon (). If the response wasn't helpful, select the dislike thumbs down icon (). When you select the thumbs up or thumbs down icon, you are prompted to provide detailed feedback by selecting one or more reason check boxes. You can also select Other to add comments or suggestions (up to 300 characters). After making your selection, select Submit to submit your feedback or select X to close the dialog without submitting feedback. All submitted feedback is captured, stored, and made available through analytic dashboards.

Figure 4. Example of additional feedback panel from thumbs down icon

Depending on the context of the response, an additional go to search results icon () may appear in the feedback icons panel. This icon appears alongside synthesized responses in Virtual Agent, clarifying questions in Virtual Agent, and regular search results or Virtual Agent fallback topics whenever a synthesized response is unavailable. Selecting the go to search results icon () redirects you to the search results page and begins a search query using the last five chat utterances you entered. Additionally, a copy message icon () appears on received Virtual Agent responses.

Extended entities and view records

Extended entity information can be found if you have activated Knowledge Graph.

Note:

To enable the Knowledge Graph natural language query (NLQ) schema, configure this schema for the assistant. To configure the schema for an assistant, see Assign search sources to a chat assistant.

These extended entities that come from the additional custom tables associated with the Knowledge Graph natural language query (NLQ) schema can include:

• Assets
• Incidents
• Recently viewed knowledge base articles
• Requests
• Tasks

Select an entity in-line citation to view that entity record in a new tab, or select View records to view a list of additional entities. Selecting a link from the View records pop-up opens a new tab with that entity table's data.

Chatting with a live agent in Virtual Agent

You can chat with a live agent if you need more support. Select the Contact Live Agent button found in the Support and settings () option, enter a request such as Chat with live agent into the chat, or select the Request a live agent fallback option. After an agent has accepted your chat, the agent's name and avatar appears at the top of the chat in a banner. Only one live agent chat at a time is permitted. To exit the live chat, select End live chat. The chat history then moves to the Closed chat section.

Figure 5. Example of the live chat banner

Submitting catalog requests

You can submit catalog requests directly from ServiceNow Otto for Virtual Agent premium chat without leaving the chat experience.

To submit a catalog request:

1. Open ServiceNow Otto for Virtual Agent premium chat.
2. Find a catalog item through chat.
3. Select the item and a catalog form opens inline in the interactive view.
4. Complete the required form fields.
5. Select Submit. A confirmation message appears and your request record is created.

Catalog submission confirmation

After you successfully submit a catalog item, a confirmation message appears with a View Details button that opens your submitted request record.

The View Details button behaves in the following ways:

• In Virtual Agent portals: Select View Details to open the submitted request record in a new browser tab. The Virtual Agent chat window shrinks to floating mode.
• In pop-out windows: If you select the pop-out icon on a submitted catalog form, the new window displays the submission confirmation page with your request details, not a blank form to start over.

Fallback options

Note:

For more information about where and how to enable fallback options, see Manage an assistant chat experience.

A fallback state can occur whenever search results are unavailable. Scenarios where search results are unavailable include the Virtual Agent didn't understand the query, complaint small talk was found, or an error occurred. When search results are unavailable, a single or multiple fallback options may appear. These fallback options include:

• Request a live chat: Triggers live agent mode and routes you to a human support representative.
• Search the web: Triggers web search mode and uses the internet to search for the results.
  Note:

  Only the last query entered into the conversation is considered when entering web search mode via this Search the web fallback option.
• Create a generic ticket: Creates a record.
• Custom fallback option: Presents a fallback Virtual Agent topic.

Select a fallback option to launch that mode or action.

Figure 6. Example of multiple fallback options

When you're using premium chat and you enter a search query through your portal's search bar, you’re redirected to the portal's search results page. At the top of the search results page, you see Genius Results in a synthesized response generated by ServiceNow Otto. This synthesized response answer provides inline citations that appear at the end of each sentence. You can select citations and if applicable, such as for conversational catalog items, select whether to Request with form or Request in chat. Similar options also appear in the regular search results area, as indicated by the request in chat icon ( ) and request with form icon (). Depending on your selection, the catalog request flow launches within either the Virtual Agent chat or a form.

Figure 7. Example of premium chat synthesized response on the portal's search results page

You can start the chat experience either through the chat icon on the portal's search results page or through the portal's chat widget button.

Figure 8. Example of chat entry points on the portal's search results page

Figure 9. Example of a chat widget button

After selecting the chat widget button on the portal, the floating chat window opens and replaces the chat button. A greeting message appears, and a chat is created only after you have entered an initial utterance. If you have an active chat ongoing, the current active chat appears instead of a greeting message. You can select a predefined action, topic, suggested search query, start a new conversation, or view all options, if applicable. The View all options link only shows if more than one suggested search query or promoted topic is available.

Note:

Any search query entered into the portal’s search bar or Virtual Agent is incorporated into the greeting topic for future conversations as a suggested search query. Suggested search queries can be viewed in the Search Suggestions [sys_search_suggestion.list] table. For more information on how to enable suggested search queries, see ServiceNow Otto for Virtual Agent system properties.

If language detection is turned on and the initial utterance entered into the portal's search bar or chat differs from the user's profile language preference, the conversational language automatically switches to the detected language. For more information and examples of language detection in premium chat conversations, see Using language detection and dynamic machine translation in Virtual Agent enhanced chat conversations.
