Product Inventory Open API

The Product Inventory Open API provides endpoints to create and retrieve product inventories.

Use this API to manage product inventory information between external systems and the ServiceNow AI Platform.

This API is included in the Product Inventory Advanced application, which is available on the ServiceNow Store.

This API is provided within the sn_prd_invt namespace.

The calling user must have the sn_prd_invt.product_inventory_integrator role.

This API creates and updates data in the following tables.

• Product Characteristics [sn_prd_invt_product_characteristics]
• Product Inventory [sn_prd_invt_product_inventory]
• Product Model [cmdb_model]
• Product Model Characteristic [sn_prd_pm_product_model_characteristic]

The Product Inventory Open API is a ServiceNow® implementation of the TM Forum Product Inventory Management API REST specification. This implementation is based on the TMF637 Product Inventory Management API User Guide v5.0.0, September 2024. The Product Inventory Open API is conformance certified by TM Forum.

Note:

By default, POST /sn_prd_invt/product accepts and returns a single JSON object. GET endpoints return status as a display label, such as Installation pending, and the product reference field is named product. To change the default behavior, create a system property sn_prd_invt.tmf637.version4 and set the value to true. When true, POST /sn_prd_invt/product accepts and returns a JSON array. GET endpoints return status as an internal value, such as installation_pending, and the product reference field is named productId. Set the property to false to return to the default behavior.

Product Inventory Open API – DELETE /sn_prd_invt/order/product/{id}

Deletes a specified product inventory record.

URL format

Default URL: /api/sn_prd_invt/order/product/{id}

Supported request parameters

Table 1. Path parameters

Name	Description
id	Sys_id of the product inventory to delete. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]

Table 2. Query parameters

Name	Description
None

Table 3. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 4. Request headers

Header	Description
Accept	Data format of the response body. Only supports application/json.

Table 5. Response headers

Header	Description
None

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 6. Status codes

Status code	Description
204	No Content. Record successfully deleted.
400	Bad Request. A bad request type or malformed request was detected.

Response body parameters (JSON)

Name	Description
None

cURL request

This example deletes a product inventory record.

curl "https://instance.service-now.com/api/sn_prd_invt/product/01b2f9972b8c72d07a83f395f291bf53" \
--request DELETE \
--header "Accept:application/json" \
--user 'username':'password'

No response body is returned when a product inventory record is successfully deleted.

Product Inventory Open API - GET /sn_prd_invt/product

Retrieves a list of all product inventories.

URL format

Default URL: api/sn_prd_invt/product

Supported request parameters

Table 7. Path parameters

Name	Description
None

Table 8. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external ID matching the value of this parameter are returned in the response. Data type: String Default: Don't filter by customer.
fields	List of fields to return in the response. Invalid fields are ignored. Data type: String Default: Return all fields.
limit	Maximum number of records to return. For requests that exceed this number of records, use the offset parameter to paginate record retrieval. Data type: Number Default: 20 Maximum: 100
offset	Starting index at which to begin retrieving records. Use this value to paginate record retrieval. This functionality enables the retrieval of all records, regardless of the number of records, in small manageable chunks. Data type: Number Default: 0
place	Filter product inventories by location. Data type: Object "place": { "id": "String" }
place.id	Sys_id or external id of the location associated with the product inventory record. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String Default: Don't filter by status.

Table 9. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 10. Request headers

Header	Description
None

Table 11. Response headers

Header	Description
Content-Range	Range of content returned in a paginated call. For example, if offset=2 and limit=3, the value of the Content-Range header is items 3-5.
Content-Type	Data format of the response body. Only supports application/json.
Link	Contains the following links to navigate through query results. first last next previous
X-Total-Count	For paginated queries, this header specifies the total number of records available on the server.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 12. Status codes

Status code	Description
200	Request successfully processed. Full resource returned in response (no pagination).
206	Partial resource returned in response (with pagination).
400	Bad request. Possible reasons: Invalid path parameter Invalid URI
404	Record not found. No records matching the query parameters are found in the table.

Response body parameters (JSON)

Name	Description
href	Relative link to the product inventory record. Data type: String
id	Sys_id of the product inventory. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
name	Name of the product inventory. Data type: String
place	Location of the product. Data type: Array "place": [ { "id": "String", "name": "String" } ]
place.id	Location sys_id or external id. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
place.name	Name of the location. Data type: String Table: Location [cmn_location] Field: name
productCharacteristic	List of product characteristics. For additional information on product characteristics, see Create a product offering category. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String", "valueType": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productCharacteristic.valueType	Type of characteristic value. Accepted values: address array.date array.datetime array.decimal array.integer array.object array.single_line_text attachment checkbox choice date date_time decimal duration email integer object single_line_text yes_no Data type: String
productId	Sys_id of the product model for the product inventory. Data type: String Table: Product Model [cmdb_model]
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Initial version or external ID of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: initial_version or external_id
productOffering.internalId	Internal version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: internal_version
productOffering.internalVersion	Version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: version
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.version	External version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: external_version
productPrice	Returns an empty array. Data type: Array
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalId": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Initial version or external ID of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: internal_version or external_id
productSpecification.internalId	Initial version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: initial_version
productSpecification.internalVersion	Version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: version
productSpecification.version	External version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: external_version
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
relatedParty.@referredType	Type of customer. Possible values: Consumer Customer CustomerContact Data type: String
state	Current state of the product. Data type: String

cURL request

This example retrieves all product inventories.

curl --location --request GET "https://instance.service-now.com/api/sn_prd_invt/product" \
--user 'username':'password'

Response body.

[
   {
      "id": "037fd87ec3603010abc8b5183c40ddf2",
      "relatedParty": [
         {
            "id": "ffc68911c35420105252716b7d40dd55",
            "name": "Example Company",
            "@type": "RelatedParty",
            "@referredType": "Customer"
         },
         {
            "id": "eaf68911c35420105252716b7d40ddde",
            "name": "Sally Thomas",
            "@type": "RelatedParty",
            "@referredType": "CustomerContact"
         }
      ],
      "name": "Routing and Configuration PI0000318",
      "productSpecification": {
         "id": "aec57e981bb420106ba59acf034bcb08",
         "name": "Routing and Configuration",
         "version": "",
         "internalVersion": "1",
         "internalId": "aec57e981bb420106ba59acf034bcb08"
      },
      "status": "Active",
      "productOffering": {
         "id": "69017a0f536520103b6bddeeff7b127d",
         "name": "Premium SD-WAN Offering",
         "version": "",
         "internalVersion": "1",
         "internalId": "69017a0f536520103b6bddeeff7b127d"
      },
      "productId": "ce0b52c7532520103b6bddeeff7b12f5",
      "place": [
         {
            "id": "25ab9c4d0a0a0bb300f7dabdc0ca7c1c",
            "name": "100 South Charles Street, Baltimore, MD"
         }
      ],
      "productCharacteristic": [],
      "productRelationship": [],
      "realizingService": [],
      "realizingResource": [
         {
            "id": "9b2fa60b536520103b6bddeeff7b1233",
            "name": "Route Target"
         }
      ],
      "productPrice": [],
      "href": "/api/sn_prd_invt/product/037fd87ec3603010abc8b5183c40ddf2",
      "billingAccount": "Not Specified."
   }
]

Product Inventory Open API - GET /sn_prd_invt/product/{id}

Retrieves a specified product inventory record.

URL format

Default URL: /api/sn_prd_invt/product/{id}

Supported request parameters

Table 13. Path parameters

Name	Description
id	Sys_id of the product inventory to retrieve. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]

Table 14. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external ID matching the value of this parameter are returned in the response. Data type: String Default: Don't filer y customer.
fields	List of fields to return in the response. Invalid fields are ignored. Data type: String Default: All fields returned.
place	Filter product inventories by location. Data type: Object "place": { "id": "String" }
place.id	Sys_id or external id of the location associated with the product inventory record. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String Default: Don't filter by status.

Table 15. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 16. Request headers

Header	Description
None

Table 17. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 18. Status codes

Status code	Description
200	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Invalid path parameter Invalid URI
404	Record not found. Record associated with the ID is not found in the table.

Response body parameters (JSON)

Name	Description
billingAccount	Billing account of the product inventory record. Data type: String
href	Relative link to the product inventory record. Data type: String
id	Sys_id of the product inventory Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
name	Name of the product inventory. Data type: String
place	Location of the product. Data type: Array "place": [ { "id": "String", "name": "String" } ]
place.id	Location sys_id or external id. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
place.name	Name of the location. Data type: String Table: Location [cmn_location] Field: name
productCharacteristic	List of product characteristics. For additional information on product characteristics, see Create a product offering category. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String", "valueType": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productCharacteristic.valueType	Type of characteristic value. Accepted values: address array.date array.datetime array.decimal array.integer array.object array.single_line_text attachment checkbox choice date date_time decimal duration email integer object single_line_text yes_no Data type: String
productId	Sys_id of the product model for the product inventory. Data type: String Table: Product Model [cmdb_model]
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Initial version or external ID of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: initial_version or external_id
productOffering.internalId	Internal version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: internal_version
productOffering.internalVersion	Version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: version
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.version	External version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: external_version
productPrice	Returns an empty array. Data type: Array
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalId": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Initial version or external ID of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: internal_version or external_id
productSpecification.internalId	Initial version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: initial_version
productSpecification.internalVersion	Version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: version
productSpecification.version	External version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: external_version
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
relatedParty.type	Type of related party. Value is always Related Party. Data type: String
relatedParty.@referredType	Type of customer, such as a customer or customer contact. Data type: String
status	Current state of the product. Data type: String

cURL request

This example retrieves a specified product inventory.

curl -X GET 'https://instance.service-now.com/api/sn_prd_invt/product/037fd87ec3603010abc8b5183c40ddf2' \
--user 'username':'password'

Output:

{
   "id": "037fd87ec3603010abc8b5183c40ddf2",
   "relatedParty": [
      {
         "id": "ffc68911c35420105252716b7d40dd55",
         "name": "Example Company",
         "@type": "RelatedParty",
         "@referredType": "Customer"
      },
      {
         "id": "eaf68911c35420105252716b7d40ddde",
         "name": "Sally Thomas",
         "@type": "RelatedParty",
         "@referredType": "CustomerContact"
      }
   ],
   "name": "Routing and Configuration PI0000318",
   "productSpecification": {
      "id": "aec57e981bb420106ba59acf034bcb08",
      "name": "Routing and Configuration",
      "version": "",
      "internalVersion": "1",
      "internalId": "aec57e981bb420106ba59acf034bcb08"
   },
   "status": "Active",
   "productOffering": {
      "id": "69017a0f536520103b6bddeeff7b127d",
      "name": "Premium SD-WAN Offering",
      "version": "",
      "internalVersion": "1",
      "internalId": "69017a0f536520103b6bddeeff7b127d"
   },
   "productId": "ce0b52c7532520103b6bddeeff7b12f5",
   "place": [
      {
         "id": "25ab9c4d0a0a0bb300f7dabdc0ca7c1c",
         "name": "100 South Charles Street, Baltimore, MD"
      }
   ],
   "productCharacteristic": [],
   "productRelationship": [],
   "realizingService": [],
   "realizingResource": [
      {
         "id": "9b2fa60b536520103b6bddeeff7b1233",
         "name": "Route Target"
      }
   ],
   "productPrice": [],
   "href": "/api/sn_prd_invt/product/037fd87ec3603010abc8b5183c40ddf2",
   "billingAccount": "Not Specified."
}

Product Inventory Open API - GET /sn_prd_invt/productinventory

Retrieves a list of all product inventories.

Important:

Starting with the Tokyo release, this endpoint is deprecated. The new version of this endpoint is Product Inventory Open API - GET /sn_prd_invt/product.

URL format

Default URL: api/sn_prd_invt/productinventory

Supported request parameters

Table 19. Path parameters

Name	Description
None

Table 20. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external ID matching the value of this parameter are returned in the response. Data type: String Default: Don't filter by customer.
fields	List of fields to return in the response. Invalid fields are ignored. Data type: String Default: All fields are returned.
limit	Maximum number of records to return. For requests that exceed this number of records, use the offset parameter to paginate record retrieval. Data type: Number Default: 20 Maximum: 100
offset	Starting index at which to begin retrieving records. Use this value to paginate record retrieval. This functionality enables the retrieval of all records, regardless of the number of records, in small manageable chunks. Data type: Number Default: 0
place	Filter product inventories by location. Data type: Object "place": { "id": "String" }
place.id	Sys_id or external id of the location associated with the product inventory record. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String Default: Don't filter by inventory status.

Table 21. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 22. Request headers

Header	Description
None

Table 23. Response headers

Header	Description
Content-Range	Range of content returned in a paginated call. For example, if offset=2 and limit=3, the value of the Content-Range header is items 3-5.
Content-Type	Data format of the response body. Only supports application/json.
Link	Contains the following links to navigate through query results. first last next previous
X-Total-Count	For paginated queries, this header specifies the total number of records available on the server.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 24. Status codes

Status code	Description
200	Request successfully processed. Full resource returned in response (no pagination).
206	Partial resource returned in response (with pagination).
400	Bad request. Possible reasons: Invalid path parameter Invalid URI
404	Record not found. No records matching the query parameters are found in the table.

Response body parameters (JSON)

Name	Description
id	Sys_id of the product inventory. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
name	Name of the product inventory. Data type: String
place	Place associated with the product. Data type: Object "place": { "id": "String", "name": "String" }
place.id	Location sys_id or external_id of the product inventory. Table: Location [cmn_location] Data: String
place.name	Name of the location associated with the product inventory. Table: Location [cmn_location] Data: String
productCharacteristic	List of product characteristics. For additional information on product characteristics, see Create a product offering category. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String", "valueType": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productCharacteristic.valueType	Type of characteristic value. Accepted values: address array.date array.datetime array.decimal array.integer array.object array.single_line_text attachment checkbox choice date date_time decimal duration email integer object single_line_text yes_no Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Sys_id of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Sys_id of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification]
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingResource.type	Type of the realizing resource. Data type: String
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingService.type	Type of the realizing service. Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact] or Consumer [csm_consumer]
relatedParty.@referredType	Type of related party. Value is always Related Party. Data type: String
relatedParty.type	Type of customer. Possible values: consumer customer customerContact Data type: String
status	Current state of the product. Data type: String

cURL request

This example retrieves all product inventories.

curl "https://instance.servicenow.com/api/sn_prd_invt/productinventory" \
--request GET \
--user 'username':'password'

Response body.

[
   {
      "id": "075072aec3a83010abc8b5183c40dd44",
      "relatedParty": [
         {
            "id": "ffc68911c35420105252716b7d40dd55",
            "name": "Funco Intl",
            "@type": "RelatedParty",
            "@referredType": "Customer"
         },
         {
            "id": "eaf68911c35420105252716b7d40ddde",
            "name": "Sally Thomas",
            "@type": "RelatedParty",
            "@referredType": "CustomerContact"
         }
      ],
      "name": "Firewall Administration PI0000300",
      "productSpecification": {
         "id": "31c5caff07266010a7955b7e0ad3006b",
         "name": "Firewall Administration"
      },
      "status": "Active",
      "productOffering": {
         "id": "",
         "name": ""
      },
      "place": {
         "id": "920cf6ac73d423002728660c4cf6a799",
         "name": "200 South James street,Atlanta, GA"
      },
      "productCharacteristic": [
         {
            "name": "Firewall Administration CPE Type",
            "valueType": "Choice",
            "value": "Physical"
         },
         {
            "name": "Configuration and Policy backup",
            "valueType": "Choice",
            "value": ""
         },
         {
            "name": "Firewall Administration CPE ID",
            "valueType": "Single Line Text",
            "value": "CPE123456789"
         },
         {
            "name": "Remote CLI troubleshoot support",
            "valueType": "Choice",
            "value": ""
         },
         {
            "name": "Firewall Administration CPE Model",
            "valueType": "Choice",
            "value": "9300 series"
         }
      ],
      "productRelationship": [],
      "realizingService": [],
      "realizingResource": [
         {
            "id": "3546463307666010a7955b7e0ad3005d",
            "name": "Cisco Firewall Management system"
         }
      ]
   },
   {
      "id": "0303a8ea74418510f877ca57242ff96d",
      "relatedParty": [
         {
            "id": "ffc68911c35420105252716b7d40dd55",
            "name": "Funco Intl",
            "@type": "RelatedParty",
            "@referredType": "Customer"
         },
         {
            "id": "eaf68911c35420105252716b7d40ddde",
            "name": "Sally Thomas",
            "@type": "RelatedParty",
            "@referredType": "CustomerContact"
         }
      ],
      "name": "SD-WAN Edge Device PI0001114",
      "productSpecification": {
         "id": "39b627aa53702010cd6dddeeff7b1202",
         "name": "SD-WAN Edge Device"
      },
      "status": "Installation Pending",
      "productOffering": {
         "id": "69017a0f536520103b6bddeeff7b127d",
         "name": "Premium SD-WAN Offering"
      },
      "place": "",
      "productCharacteristic": [],
      "productRelationship": [],
      "realizingService": [
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         },
         {
            "id": "16d79ec3532520103b6bddeeff7b12a6",
            "name": "SD WAN Optimization Service"
         },
         {
            "id": "16d79ec3532520103b6bddeeff7b12a6",
            "name": "SD WAN Optimization Service"
         },
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         },
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         },
         {
            "id": "bf65eadc1b7420106ba59acf034bcb57",
            "name": "SD-WAN Routing"
         }
      ],
      "realizingResource": [
         {
            "id": "493fa60b536520103b6bddeeff7b12b6",
            "name": "Customer Premise SD-WAN Router"
         }
      ]
   }
]

Product Inventory Open API - GET /sn_prd_invt/productinventory/{inventoryId}

Retrieves a product inventory.

Important:

Starting with the Tokyo release, this endpoint is deprecated. The new version of this endpoint is Product Inventory Open API - GET /sn_prd_invt/product/{id}.

URL format

Default URL: /api/sn_prd_invt/productinventory/{inventoryId}

Supported request parameters

Table 25. Path parameters

Name	Description
inventoryId	Sys_id of the product inventory to retrieve. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]

Table 26. Query parameters

Name	Description
customer	Filter product inventories by customer. Only product offerings with a customer sys_id or external ID matching the value of this parameter are returned in the response. Data type: String
fields	List of fields to return in the response. Invalid fields are ignored. Data type: String Default: All fields returned.
place	Filter product inventories by location. Data type: Object "place": { "id": "String" }
place.id	Sys_id or external id of the location associated with the product inventory record. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
status	Filter product inventories by status. Only product inventories with a status matching the value of this parameter are returned in the response. Data type: String

Table 27. Request body parameters (JSON)

Name	Description
None

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 28. Request headers

Header	Description
None

Table 29. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 30. Status codes

Status code	Description
200	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Invalid path parameter Invalid URI
404	Record not found. Record associated with the ID is not found in the table.

Response body parameters (JSON)

Name	Description
id	Sys_id of the product inventory Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
name	Name of the product inventory. Data type: String
place	Place associated with the product. Data type: Object "place": { "id": "String", "name": "String" }
place.id	Location sys_id or external_id of the product inventory. Table: Location [cmn_location] Data: String
place.name	Name of the location associated with the product inventory. Table: Location [cmn_location] Data: String
productCharacteristic	List of product characteristics. For additional information on product characteristics, see Create a product offering category. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String", "valueType": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productCharacteristic.valueType	Type of characteristic value. Accepted values: address array.date array.datetime array.decimal array.integer array.object array.single_line_text attachment checkbox choice date date_time decimal duration email integer object single_line_text yes_no Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Sys_id of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Sys_id of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification]
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingResource.type	Type of the realizing resource. Data type: String
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingService.type	Type of the realizing service. Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
relatedParty.@referredType	Type of related party. Value is always Related Party. Data type: String
relatedParty.type	Type of customer. Possible values: consumer customer customerContact Data type: String
status	Current state of the product. Data type: String

cURL request

This example retrieves a product inventory for an SD-WAN service package.

curl --location --request GET 'https:// instance.servicenow.com/api/sn_prd_invt/productinventory/074450fc74918d10f877ca57242ff9e3' \
--user 'username':'password'

Output:

{
   "id": "074450fc74918d10f877ca57242ff9e3",
   "relatedParty": [
      {
         "id": "ffc68911c35420105252716b7d40dd55",
         "name": "Funco Intl",
         "@type": "RelatedParty",
         "@referredType": "Customer"
      },
      {
         "id": "eaf68911c35420105252716b7d40ddde",
         "name": "Sally Thomas",
         "@type": "RelatedParty",
         "@referredType": "CustomerContact"
      }
   ],
   "name": "SD-WAN Service Package PI0001576",
   "productSpecification": {
      "id": "cfe5ef6a53702010cd6dddeeff7b12f6",
      "name": "SD-WAN Service Package"
   },
   "status": "Installation Pending",
   "productOffering": {
      "id": "69017a0f536520103b6bddeeff7b127d",
      "name": "Premium SD-WAN Offering"
   },
   "place": "",
   "productCharacteristic": [],
   "productRelationship": [
      {
         "id": "a74490fc74918d10f877ca57242ff942",
         "name": "SD-WAN Edge Device PI0001582",
         "relationshipType": "Bundles"
      },
      {
         "id": "b85414fc74918d10f877ca57242ff90e",
         "name": "SD-WAN Controller PI0001602",
         "relationshipType": "Bundles"
      },
      {
         "id": "d74490fc74918d10f877ca57242ff907",
         "name": "SD-WAN Security PI0001577",
         "relationshipType": "Bundles"
      }
   ],
   "realizingService": [],
   "realizingResource": []
}

Product Inventory Open API – PATCH /sn_prd_invt/order/product/{id}

Updates a specified product inventory record.

URL format

Default URL: /api/sn_prd_invt/order/product/{id}

Supported request parameters

Table 31. Path parameters

Name	Description
id	Sys_id of the product inventory to update. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]

Table 32. Query parameters

Name	Description
None

Table 33. Request body parameters (JSON)

Name	Description
bundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean
name	Name of the product inventory. Data type: String
place	Location of the product. Data type: Array "place": [ { "id": "String", "name": "String" } ]
place.id	Location sys_id or external id. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
place.name	Name of the location. Data type: String Table: Location [cmn_location] Field: name
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "@referredType": "String", "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "status": "String", "version": "String" }
productOffering.@referredType	This value is always ProductOffering. Data type: String
productOffering.id	Initial version or external ID of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: initial_version or external_id
productOffering.internalId	Internal version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: internal_version
productOffering.internalVersion	Version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: version
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: name
productOffering.status	Status of the product offering. Possible values: archived draft published retired Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: status
productOffering.version	External version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: external_version
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "@referredType": "String", "@type": "String", "id": "String", "name": "String" } ]
relatedParty.@referredType	Type of related party. Possible values: Consumer Customer CustomerContact Data type: String
relatedParty.@type	This value is always RelatedParty. Data type: String
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
relatedParty.name	Name of the of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 34. Request headers

Header	Description
Accept	Data format of the response body. Only supports application/json.
Content-Type	Data format of the request body. Only supports application/json.

Table 35. Response headers

Header	Description
None

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 36. Status codes

Status code	Description
200	Successful. The request was successfully processed.
400	Bad Request. A bad request type or malformed request was detected.
404	Not found. The requested item wasn't found.

Response body parameters (JSON)

Name	Description
bundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean
name	Name of the product inventory. Data type: String
place	Location of the product. Data type: Array "place": [ { "id": "String", "name": "String" } ]
place.id	Location sys_id or external id. Data type: String Table: Location [cmn_location] Field: sys_id or sn_tmt_core_external_id
place.name	Name of the location. Data type: String Table: Location [cmn_location] Field: name
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "@referredType": "String", "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "status": "String", "version": "String" }
productOffering.@referredType	This value is always ProductOffering. Data type: String
productOffering.id	Initial version or external ID of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: initial_version or external_id
productOffering.internalId	Internal version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: internal_version
productOffering.internalVersion	Version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: version
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: name
productOffering.status	Status of the product offering. Possible values: archived draft published retired Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: status
productOffering.version	External version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: external_version
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "@referredType": "String", "@type": "String", "id": "String", "name": "String" } ]
relatedParty.@referredType	Type of related party. Possible values: Consumer Customer CustomerContact Data type: String
relatedParty.@type	This value is always RelatedParty. Data type: String
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
relatedParty.name	Name of the of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]

cURL request

This example updates a product inventory record.

curl "https://instance.service-now.com/api/sn_prd_invt/product/036e506510322250f8777d910acbd77f" \
--request PATCH \
--header "Accept:application/json" \
--header "Content-Type:application/json" \
--data "{
   \"name\": \"Internet Plan\",
   \"productOffering\": {
      \"@referredType\": \"ProductOffering\",
      \"name\": \"Premium SD-WAN Offering\",
      \"id\": \"0361dd9fd0a63110f8770dbf976be16f\"
   },
   \"relatedParty\": [
      {
         \"@referredType\": \"CustomerContact\",
         \"@type\": \"RelatedParty\",
         \"name\": \"Sally Thomas\",
         \"id\": \"f3af54c413651200042ab3173244b053\"
      },
      {
         \"@referredType\": \"Customer\",
         \"@type\": \"RelatedParty\",
         \"name\": \"Funco Intl\",
         \"id\": \"ffc68911c35420105252716b7d40dd55\"
      }
   ],
   \"bundle\": false,
   \"place\": [
      {
         \"id\": \"25ab9c4d0a0a0bb300f7dabdc0ca7c1c\",
         \"name\": \"100 South Charles Street, Baltimore, MD\"
      }
   ]
}" \
--user 'username':'password'

Response body.

{
   "name": "Internet Plan",
   "productOffering": {
      "@referredType": "ProductOffering",
      "name": "Premium SD-WAN Offering",
      "id": "0361dd9fd0a63110f8770dbf976be16f",
      "internalVersion": "1",
      "version": "",
      "status": "published",
      "internalId": "0361dd9fd0a63110f8770dbf976be16f"
   },
   "relatedParty": [
      {
         "@referredType": "CustomerContact",
         "@type": "RelatedParty",
         "name": "Sally Thomas",
         "id": "f3af54c413651200042ab3173244b053"
      },
      {
         "@referredType": "Customer",
         "@type": "RelatedParty",
         "name": "Funco Intl",
         "id": "ffc68911c35420105252716b7d40dd55"
      }
   ],
   "bundle": false,
   "place": [
      {
         "id": "25ab9c4d0a0a0bb300f7dabdc0ca7c1c",
         "name": "100 South Charles Street, Baltimore, MD"
      }
   ],
   "productPrice": [],
   "id": "036e506510322250f8777d910acbd77f",
   "href": "/api/sn_prd_invt/product/036e506510322250f8777d910acbd77f"
}

Product Inventory Open API - POST /sn_prd_invt/product

Creates a product inventory record.

URL format

Default URL: /api/sn_prd_invt/product

Supported request parameters

Table 37. Path parameters

Name	Description
None

Table 38. Query parameters

Name	Description
None

Table 39. Request body parameters (JSON)

Name	Description
bundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean Default: false
isBundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean Default: false
name	Required. Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String Default: Blank string
productCharacteristic	List of product characteristics. For additional information on product characteristics, see Create a product offering category. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String", "valueType": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String Default: Blank string
productCharacteristic.value	Value of the characteristic. Data type: String Default: Blank string
productCharacteristic.valueType	Type of characteristic value. Accepted values: address array.date array.datetime array.decimal array.integer array.object array.single_line_text attachment checkbox choice date date_time decimal duration email integer object single_line_text yes_no Data type: String
productOffering	Required. Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Required. Initial_version or external_id of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.internalVersion	Version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: version
productOffering.name	Name of the product offering. Data type: String Default: Blank string Table: Product Offering [sn_prd_pm_product_offering]
productOffering.version	External version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: external_version
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Required if using the productRelationship parameter. Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. The only valid value is child. Data type: String Default: Blank string
productSpecification	Required. Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Required. Initial_version or external_id of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification]
productSpecification.internalVersion	Version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: version
productSpecification.version	External version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: external_version
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Required if using the realizingResource parameter. Sys_id of the realizing resource. Data type: String
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Required if using the realizingService parameter. Sys_id of the realizing service. Data type: String
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.@referredType	Type of customer. Possible values: consumer customer customer_contact Data type: String Default: Blank string
relatedParty.id	Required if using the relatedParty parameter. Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
state	Current state of the product. Possible values: active change_pending inactivation_pending inactive installation_pending Data type: String Default: installation_pending

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 40. Request headers

Header	Description
Accept	Data format of the response body. Only supports application/json.
Content-Type	Data format of the request body. Only supports application/json.

Table 41. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 42. Status codes

Status code	Description
201	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Empty payload. Invalid payload. Mandatory field missing: <field name>

Response body parameters (JSON)

Name	Description
bundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean
href	Relative link to the product inventory record. Data type: String
id	Sys_id of the product inventory. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
isBundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean
name	Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String
productCharacteristic	List of product characteristics. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "internalId": "String", "internalVersion": "String", "name": "String", "version": "String" }
productOffering.id	Initial version or external ID of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: initial_version or external_id
productOffering.internalId	Internal version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: internal_version
productOffering.internalVersion	Version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: version
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.version	External version of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering] Field: external_version
productPrice	Returns an empty array. Data type: Array
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String", "internalId": "String", "internalVersion": "String", "version": "String" }
productSpecification.id	Initial version or external ID of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: internal_version or external_id
productSpecification.internalId	Initial version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: initial_version
productSpecification.internalVersion	Version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: version
productSpecification.version	External version of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification] Field: external_version
realizingResource	Resource that realizes the product. The realizing resource is a child product inventory of this product inventory. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingResource.type	Type of the realizing resource. Valid value: child Data type: String
realizingService	Service that realizes the product. The realizing service is a child product inventory of this product inventory. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingService.type	Type of the realizing service. Valid value: child Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.@referredType	Type of related party. Value is always Related Party. Data type: String
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table:Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
relatedParty.type	Type of customer. Possible values: consumer customer customerContact Data type: String
status	Current state of the product. Data type: String

cURL request

This example creates a product inventory for a voice over IP solution for a user.

curl -X POST "https://instance.service-now.com/api/sn_prd_invt/product" \
--header "Accept: application/json" \
--header "Content-Type: application/json" \
--user "username":"password" \
--data "[
   {
      "pid": "PO-456",
      "description": "inventory description",
      "isBundle": false,
      "name": "Voice Over IP Basic instance for Jean",
      "productOffering": {
         "@referredType": "ProductOffering",
         "name": "Premium SD-WAN Offering",
         "id": "69017a0f536520103b6bddeeff7b127d"
      },
      "productCharacteristic": [],
      "productRelationship": [
         {
            "productId": "fa6d13f45b5620102dff5e92dc81c77f",
            "relationshipType": "child"
         }
      ],
      "realizingService": {
         "id": "fe6d13f45b5620102dff5e92dc81c786",
         "relationshipType": "child"
      },
      "realizingResource": {
         "id": "326d13f45b5620102dff5e92dc81c78c",
         "relationshipType": "child"
      },
      "relatedParty": [
         {
            "@referredType": "CustomerContact",
            "@type": "RelatedParty",
            "name": "Sally Thomas",
            "id": "eaf68911c35420105252716b7d40ddde"
         },
         {
            "@referredType": "Customer",
            "@type": "RelatedParty",
            "name": "Funco Intl",
            "id": "ffc68911c35420105252716b7d40dd55"
         }
      ],
      "productSpecification": {
         "@referredType": "ProductSpecification",
         "@type": null,
         "name": null,
         "id": "3ee1fdb1c3331010d216b5183c40dd81",
         "internalVersion": "1"
      },
      "bundle": false
   }
]"

Response body.

{
   "pid": "PO-456",
   "description": "inventory description",
   "isBundle": false,
   "name": "Voice Over IP Basic instance for Jean",
   "productOffering": {
      "@referredType": "ProductOffering",
      "name": "Premium SD-WAN Offering",
      "id": "69017a0f536520103b6bddeeff7b127d",
      "internalVersion": "1",
      "version": null,
      "status": "published",
      "internalId": "69017a0f536520103b6bddeeff7b127d"
   },
   "productCharacteristic": [],
   "productRelationship": [
      {
         "productId": "fa6d13f45b5620102dff5e92dc81c77f",
         "relationshipType": "child"
      }
   ],
   "realizingService": {
      "id": "fe6d13f45b5620102dff5e92dc81c786",
      "relationshipType": "child"
   },
   "realizingResource": {
      "id": "326d13f45b5620102dff5e92dc81c78c",
      "relationshipType": "child"
   },
   "relatedParty": [
      {
         "@referredType": "CustomerContact",
         "@type": "RelatedParty",
         "name": "Sally Thomas",
         "id": "eaf68911c35420105252716b7d40ddde"
      },
      {
         "@referredType": "Customer",
         "@type": "RelatedParty",
         "name": "Example Company",
         "id": "ffc68911c35420105252716b7d40dd55"
      }
   ],
   "productSpecification": {
      "@referredType": "ProductSpecification",
      "@type": null,
      "name": null,
      "id": "3ee1fdb1c3331010d216b5183c40dd81",
      "internalVersion": "1",
      "version": null,
      "status": "published",
      "internalId": "3ee1fdb1c3331010d216b5183c40dd81"
   },
   "bundle": false,
   "productPrice": [],
   "id": "25b07475471789108761b955d36d439d",
   "href": "/api/sn_prd_invt/product/25b07475471789108761b955d36d439d"
}

Product Inventory Open API - POST /sn_prd_invt/productinventory

Creates a product inventory.

Important:

Starting with the Tokyo release, this endpoint is deprecated. The new version of this endpoint is Product Inventory Open API - POST /sn_prd_invt/product.

URL format

Default URL: /api/sn_prd_invt/productinventory

Supported request parameters

Table 43. Path parameters

Name	Description
None

Table 44. Query parameters

Name	Description
None

Table 45. Request body parameters (JSON)

Name	Description
isBundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean Default: false
name	Required. Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String Default: Blank string
productCharacteristic	List of product characteristics. For additional information on product characteristics, see Create a product offering category. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String", "valueType": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String Default: Blank string
productCharacteristic.value	Value of the characteristic. Data type: String Default: Blank string
productCharacteristic.valueType	Type of characteristic value. Accepted values: address array.date array.datetime array.decimal array.integer array.object array.single_line_text attachment checkbox choice date date_time decimal duration email integer object single_line_text yes_no Data type: String
productOffering	Required. Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Required. Sys_id of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.name	Name of the product offering. Data type: String Default: Blank string Table: Product Offering [sn_prd_pm_product_offering]
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Required if using the productRelationship parameter. Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. The only valid value is child. Data type: String Default: Blank string
productSpecification	Required. Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Required. Sys_id of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification]
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Required if using the realizingResource parameter. Sys_id of the realizing resource. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingResource.type	Type of the realizing resource. The only valid value is child. Data type: String Default: Blank string
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Required if using the realizingService parameter. Sys_id of the realizing service. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingService.type	Type of the realizing service. The only valid value is child. Data type: String Default: Blank string
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.@referredType	Type of customer. Possible values: consumer customer customer_contact Data type: String Default: Blank string
relatedParty.id	Required if using the relatedParty parameter. Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_Consumer]
state	Current state of the product. Possible values: active change_pending inactivation_pending inactive installation_pending Data type: String Default: installation_pending

Headers

The following request and response headers apply to this HTTP action only, or apply to this action in a distinct way. For a list of general headers used in the REST API, see Supported REST API headers.

Table 46. Request headers

Header	Description
Accept	Data format of the response body. Only supports application/json.
Content-Type	Data format of the request body. Only supports application/json.

Table 47. Response headers

Header	Description
Content-Type	Data format of the response body. Only supports application/json.

Status codes

The following status codes apply to this HTTP action. For a list of possible status codes used in the REST API, see REST API HTTP response codes.

Table 48. Status codes

Status code	Description
201	Request successfully processed.
400	Bad Request. Could be any of the following reasons: Empty payload. Invalid payload. Mandatory field missing: <field name>

Response body parameters (JSON)

Name	Description
id	Sys_id of the product inventory. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
isBundle	Flag that indicates whether the product inventory record is part of a bundled product. Valid values: true: Is part of a bundle. false: Isn't part of a bundle. Data type: Boolean
name	Name of the product inventory. Data type: String
pid	Unique identifier for the product inventory from the external system. Data type: String
productCharacteristic	List of product characteristics. Data type: Array of Objects "productCharacteristic": [ { "name": "String", "value": "String" } ]
productCharacteristic.name	Name of the characteristic. Data type: String
productCharacteristic.value	Value of the characteristic. Data type: String
productOffering	Product offering that the product inventory is associated with. Data type: Object "productOffering": { "id": "String", "name": "String" }
productOffering.id	Sys_id of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productOffering.name	Name of the product offering. Data type: String Table: Product Offering [sn_prd_pm_product_offering]
productRelationship	List of related products. Data type: Array of Objects "productRelationship": [ { "productId": "String", "relationshipType": "String" } ]
productRelationship.productId	Sys_id of the related product. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
productRelationship.relationshipType	Type of relationship. Data type: String
productSpecification	Product specification for the product. Data type: Object "productSpecification": { "id": "String" }
productSpecification.id	Sys_id of the product specification. Data type: String Table: Product Specification [sn_prd_pm_product_specification]
realizingResource	Realizing resource. Data type: Object "realizingResource": { "id": "String", "type": "String" }
realizingResource.id	Sys_id of the realizing resource Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingResource.type	Type of the realizing resource. Data type: String
realizingService	Realizing service. Data type: Object "realizingService": { "id": "String", "type": "String" }
realizingService.id	Sys_id of the realizing service. Data type: String Table: Product Inventory [sn_prd_invt_product_inventory]
realizingService.type	Type of the realizing service. Data type: String
relatedParty	List of parties associated with the ticket. Data type: Array of Objects "relatedParty": [ { "id": "String", "@referredType": "String" } ]
relatedParty.id	Sys_id of the account or customer contact associated with the ticket. Data type: String Table: Account [customer_account], Contact [customer_contact], or Consumer [csm_consumer]
relatedParty.@referredType	Type of customer. Possible values: Consumer Customer CustomerContact Data type: String
state	Current state of the product. Data type: String

cURL request

This example creates a product inventory for a voice over IP solution for a user.

curl --location --request POST "https://instance.servicenow.com/api/sn_prd_invt/productinventory" \
--header "Content-Type: application/json" \
--data-raw '[
    {
        "pid": "demoInventory",
        "description": "inventory description",
        "isBundle": false,
        "name": "Voice Over IP Basic instance for Jean",
        "productOffering": {
            "id": "69017a0f536520103b6bddeeff7b127d",
            "name": "Premium SD-WAN Offering",
            "@referredType": "ProductOffering"
        },
        "productCharacteristic": [
            {
                "name": "CPE Type",
                "valueType": "choice",
                "value": "Virtual"
            },
            {
                "name":"Routing",
                "valueType": "choice",
                "value": "Premium"
            }
        ],
        "productRelationship": [
            {
                "productId": "7e6d13f45b5620102dff5e92dc81c787",
                "relationshipType": "child"
            }
        ],
        "relatedParty": [
            {
                "id": "eaf68911c35420105252716b7d40ddde",
                "name": "Sally Thomas",
                "role": "User",
                "@type": "RelatedParty",
                "@referredType": "CustomerContact"
            },
            {
                "id": "ffc68911c35420105252716b7d40dd55",
                "name": "Funco Intl",
                "@type": "RelatedParty",
                "@referredType": "Customer"
            }
        ],
        "productSpecification": {
            "id": "cfe5ef6a53702010cd6dddeeff7b12f6",
            "@referredType": "ProductSpecification",
            "version": "1"
        }
    }
]'
--user 'username':'password'

Response body.

{
   "pid": "demoInventory",
   "description": "inventory description",
   "isBundle": false,
   "name": "Voice Over IP Basic instance for Jean",
   "productOffering": {
      "id": "69017a0f536520103b6bddeeff7b127d",
      "name": "Premium SD-WAN Offering",
      "@referredType": "ProductOffering"
   },
   "productCharacteristic": [
      {
         "name": "CPE Type",
         "valueType": "choice",
         "value": "Virtual"
      },
      {
         "name": "Routing",
         "valueType": "choice",
         "value": "Premium"
      }
   ],
   "productRelationship": [
      {
         "productId": "7e6d13f45b5620102dff5e92dc81c787",
         "relationshipType": "child"
      }
   ],
   "relatedParty": [
      {
         "id": "eaf68911c35420105252716b7d40ddde",
         "name": "Sally Thomas",
         "role": "User",
         "@type": "RelatedParty",
         "@referredType": "CustomerContact"
      },
      {
         "id": "ffc68911c35420105252716b7d40dd55",
         "name": "Funco Intl",
         "@type": "RelatedParty",
         "@referredType": "Customer"
      }
   ],
   "productSpecification": {
      "id": "cfe5ef6a53702010cd6dddeeff7b12f6",
      "@referredType": "ProductSpecification",
      "version": "1"
   },
   "id": "3ac715c6745d8150f877ca57242ff97a"
}
