Look Up Record action
Look up a record from any table based on defined conditions.
Roles and availability
Available as a Workflow Studio ServiceNow core action. Users with the flow_designer or admin role can add an action to a flow and define configuration details.
Fields
| Field | Description |
|---|---|
| Table | Select a table from the list. |
| Conditions |
Conditions the returned record must meet. When building a condition that looks up the value of a reference field, use a data pill that explicitly provides the Sys ID value. Ensure the condition has the format [reference field][is][Reference type data pill->Sys ID]. For example, both the Change and Incident tables contain a reference field to the User table. To look up change records where the requester is the caller from an incident record, create the condition [Requested by][is][Trigger->incident record->Caller->Sys ID]. |
| Order by | Determines how to sort results when more than one record matches the defined conditions. Select the field you want to use to sort results. |
| Sort Type | Select whether to sort alphabetically in ascending or descending order. |
| If multiple records are found | Determines what information to return when more than one record matches the defined conditions.
|
| Don't fail on error | Determines whether to fail the flow when the lookup can't find a record. |
Outputs
These outputs appear in the Data panel. You can use them as inputs elsewhere in your flow.
- Record
- Data type: Record
Record found based on the conditions you specified in the Conditions input.
- Table
- Data type: Table
Name of the table associated with the returned record.
- Status
- Data type: Choice
0 if a record was found successfully, and 1 if there was an error.
- Error Message
- Data type: String
Message containing details about why the record could not be found.
Note:This output's value is only populated if the Status output's value is 1.
