Add Platform Analytics pages to a configurable workspace

  • Release version: Zurich
  • Updated July 31, 2025
  • 2 minutes to read

    • Add an Analytics Center and its related pages to your own workspace/experience through page templates.

    Before you begin

    Role required: ui_builder_admin

    About this task

    In experiences and workspaces, the Analytics Center provides a central page with tabs for all the other pages related to Platform Analytics. You do not have to add an Analytics Center, but this procedure uses that page as example. The same procedure applies to adding the other Platform Analytics pages from templates. Details about those pages are provided at the end of this topic.

    Procedure

    1. Open your experience in the UI Builder.
    2. Scroll to the desired template.
      This procedure shows how to set up the Analytics Center template, but the instructions apply to any template, such as Dashboards.
    3. Hold your cursor over the Analytics Center template and select Use template.

      The Analytics Center template selected.

    4. Specify a name and a path for the page and press Continue.
    5. In the URL parameters page, press Looks good.
    6. Optional: Specify the variant name, audiences, and conditions.
    7. Press Create.
      The page editor opens.
    8. Change from the Editor to the Settings view.

      The Settings button on a UI Builder page.
    9. Select the General variant.
      The General choice in the variants.
    10. Under URL parameters, add the following optional parameters:
      • tab
      • filter

      These parameters ensure that on page refresh, the last open tab of the Analytics Center opens. Also, the last selected filter (such as Bookmarked) is enabled.

    11. Press Save.

    Result

    You now have a page with a fully configured Analytics Center, including all components. However, none of the links to other pages work until those pages are added and configured.

    What to do next

    Create pages using the following templates. Follow the same process you used to create the Analytics Center page. Give the pages the following paths and parameters:

    Note:
    • The default event handlers use the paths in this table. If you specify a different path, you have to customize the event handler as described in Configure custom redirection from a dashboard component.
    • Simple List and Dashboard overview are legacy page templates, like Analytics Center. You must specify the parameters manually for these pages. Newer page templates give you the parameters in the course of page creation.
    • Platform Analytics is modular. You can create only some of the pages and get their standalone functions. For example, if you only want dashboard support or KPI Details, create the pages with that functionality and don't create an Analytics Center.
    Template name Function Required parameters Optional parameters Path

    KPI Details

    		 Displays the details of a single indicator uuid scoreDate, breakdowns, domain, aggregate ac_kpi_details
    Simple List Displays a list of table records table listTitle, query, disableInlineEditing, listView simplelist
    Standard record Displays the details of a table record table, sysId query, extraParams, views, selectedTabIndex record
    Dashboard overview Displays all dashboard tiles none none all-dashboards
    Dashboards (see Add a dashboard to a Dashboards page) Used to create, edit, and show dashboards along with data visualizations inside those dashboards. This page template is the minimum requirement for dashboard support. none edit, sysId, tabSysId, filter, element dashboards
    Visualization designer Used to create and edit data visualizations independently of dashboards, without using the Dashboards editor. sysid none visualization-designer
    Important:
    You must use these paths, which are the same paths of the pages in the Platform Analytics experience. The preconfigured event handlers on the pages use these paths. If you do not give your pages these paths, the event handlers will not work.
